Large-Cyclone Powder Spraying System for Branded Educational Equipment

Product Details

Payment & Shipping Terms

Get Best Price

Product Details

Product Description

Highlight:
                                                Large-Cyclone Powder Spraying System, Automatic Powder Coating Line, Branded Educational Equipment Powder Spray


Large-Cyclone Powder Spraying System for Branded Educational Equipment

Equipment Overview

Automated electrostatic powder coating system designed for metal educational equipment, featuring high-efficiency powder recovery and environmentally friendly coating pre-treatment solutions.

Working Principle

PLC-controlled system manages powder spray pressure, electrostatic voltage, and reciprocator stroke. Educational equipment workpieces undergo multiple processing stages including automatic spraying, overspray collection, large-cyclone separation, and secondary fine filtration.

Core Advantages

Full Automation: Continuous multi-variety batch production with minimal manual intervention
High Precision Coating: Programmable parameters ensure consistent thickness and color on irregular surfaces
Energy Efficient Operation: Large-cyclone separation system minimizes powder waste and reduces energy consumption
Wide Application Range: Suitable for school furniture, teaching instruments, sports equipment, and electronic enclosures

Process Flow

Loading & Conveying → Electrostatic Powder Booth Entry → Automatic Electrostatic Powder Coating → Manual Touch-Up → Overspray Powder Large-Cyclone Separation → Sieve Machine Recycling → Exhaust Gas Secondary Filtration & Discharge → Curing Oven Transfer → Unloading

System Components

Component	Description
Powder Spraying System	High-penetration electrostatic guns with fan/round nozzles, anti-static hoses, precision pressure sensors, and integrated fluidized hoppers
Conveying System	Overhead suspension chain (0.5-5 m/min adjustable), rotation mechanisms for full coverage, conductive grounding
Powder Booth Structure	PP/PVC engineering plastic construction, partitioned zones, double-layer dust-proof powder supply with automatic replenishment
Filtration & Circulation	Large-cyclone separator (≥96% efficiency) + rotary cartridge filters (≤2μm precision), explosion-proof exhaust fans
Heating & Control	Gas-fired hot-air circulation, PID temperature control, PT100 sensors, intelligent controllers
Intelligent Control	PLC (Siemens S7-1200) + HMI touchscreen, recipe storage, fault alarms, production reporting
Auxiliary Systems	Exhaust filtration, emergency stops, insulated platforms, explosion-proof cabinets, fire suppression

Key Features

Cost-Effective Performance: 98% powder recycling rate with optimal cost-performance for frequent color changes

Advanced Engineering: State-of-the-art plastic powder booths and large-cyclone recovery modules

Future-Ready Design: Expandable system with capacity for spraying robots and increased production demands

Quality Certified: ISO 9001 compliant with rigorous control of airflow, sealing, and coating thickness standards
