Precise Coating Hanging Conveyor System Automatic Environmental Protection Equipment

Instructions:

Accumulation chain painting production line equipment is a highly automated spraying equipment, through the precise control system and efficient spraying equipment, to achieve fast and uniform spraying of the workpiece ‌. The coating production line usually adopts suspension chain or ground conveying chain and other conveying methods to continuously and stably send the workpiece to be sprayed into the spraying area. Within the spray area, multiple nozzles apply precise spray according to preset procedures, ensuring uniform and high quality coating for each workpiece ‌. Equipment advantages ‌‌ efficiency ‌ : The stacking chain coating line can realize continuous and large quantities of spraying operations, significantly improving production efficiency. At the same time, due to its high degree of automation, manual participation is reduced, and the production cycle is further shortened ‌. ‌ precision ‌ : Through the advanced control system and accurate nozzle design, the accumulation chain coating line can achieve accurate spraying of the workpiece to ensure uniform coating and high quality ‌.
‌ Environmental protection ‌ : equipped with automatic powder cleaning and color changing cyclone powder recovery device and environmental protection equipment, making the painting process more environmentally friendly and efficient ‌

Main structure and components:

The production line is mainly composed of power system, traction chain, storage track, bearing car group, turnout, control system and other key components and structures ‌. The automatic painting line of stacking chain is specifically composed of a number of key components, such as power system, traction straight rail, traction bent rail, bearing straight rail, bearing bent rail, bearing car group, combined channel metal, branch switches, stopper and electric control system. These components work together to ensure the efficient and stable operation of the production line ‌. In addition, the accumulation type suspension conveying system is also an important part of the accumulation chain coating production line, which is composed of the accumulation track, traction chain, load car, driving device, tensioning device, steel structure, emergency stop switch, etc. The load trolley carries the workpiece up and down the line through the traction chain conveying system, and automatically transmits it to each station to complete the painting work ‌

Features:

1. High cost performance Based on the customer's product positioning and development strategy, based on economic benefits, to achieve the best cost performance.

2.Advanced equipment design concept of excellence, high degree of automation of industrial equipment, show modern advanced enterprise style.

3.High adaptability to meet the current production requirements, and reserve space for development, considering the later production increase and quality improvement needs.

4.Quality standards strictly follow the IS0900 quality management system, and every small link of the entire equipment installation is strictly checked.
